SPECIFICATIONS:

• Motor: 5 HP, 230V, 3-phase, 16.5A
• Required power supply: 230V, 3-phase, minimum 20A circuit
• Maximum cutter height: 5"
• Maximum cutter diameter: 7"
• Spindle diameters: 3/4", 1-1/4"
• Spindle lengths: 3-7/8", 5-7/8"
• Spindle capacities under nut: 3-1/2", 5-1/8"
• Spindle speed: Variable, 5000–10,000 RPM
• Spindle travel: 4"
• Spindle openings: 2-1/2", 4-1/8", 5-3/4", 7"
• Table counterbore: 8-1/4"dia., 3/16" depth
• Table size: 31-1/2" x 39-1/4"
• Floor-to-table height: 36-1/4"
• Footprint: 25-1/2" x 31"
• Dimensions: 39-1/2" W x 34" D x 51-1/2" H
• Approx. shipping weight: 800 lbs.

FEATURES:

• DRO for spindle RPM and height positioning
• 4-3/4" tall anodized aluminum fence with featherboard attachments
• Rack-and-pinion fence adjustment with 4" of travel
• Micro-adjustment knobs for fence alignment
• Power feeder attachment locations (power feeder not included)
• Variable speed, from 5000–10,000 RPM
• Fully adjustable clear guard
• Dual 4" dust ports
• Quick-release belt tensioner
• US based customer service and technical support
