Specifications:

• Swing over bed: 16-1/2"
• Swing over saddle: 11-1/2"
• Drawbar: 3/8" - 16 TPI
• Tailstock barrel travel: 1-1/2"
• Lathe max tool size: 1/2"
• Number of Mill/Drill speeds: 14
• Speed range: 135, 175, 240, 295, 315, 380, 390, 490, 505, 635, 695, 900, 1055, 1370 RPM
• Number of Lathe speeds: 7

• Lathe speed range: 185, 330, 405, 535, 680, 955, 1455 RPM
• Range of threads (inches): 8 - 120 TPI in 27 steps (Gear changes required)
• Range of threads (metric): 18 @ 0.2 - 3.0 mm

Standard Equipment:

• 4" 3-jaw chuck
• 1/2" drill chuck
• MT#3 chuck arbor
• 2 dead centers
• Change gears
• 5" backplate
• 9-1/2" face plate

Features:

• Cross Slide Doubles as a Mill Table
• Coarse and Fine Mill Spindle Downfeed
• 4-Way Turret Tool Post
• Tailstock Offsets 1/2"
• 14 Mill Spindle Speeds
• 7 Lathe Spindle Speeds
• 4" 3-Jaw Chuck Included
• 9-1/2" Faceplate Included
•
